Mercury Sable IV (1999-2005) roof opening panel motor assembly Wiring diagram
This page shows the only wiring diagram for the component.roof opening panel motor assembly, which is found in the car Mercury Sable IV (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roof opening panel motor assembly (1 of 1)
ACCESSORY RELAY
BATTERY SAVER RELAY
BLK WIRE
BLK/LT BLU WIRE
BLU WIRE
BRN WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDEOF DASH)
CIRCUIT BREAKER 10
CLOSE UP OPEN
FUSE 11
FUSE 26
GENERIC ELECTRONIC MODULE (GEM) (UNDER LEFT SIDE OF DASH)
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
ROOF OPENING PANEL MODULE
ROOF OPENING PANEL MOTOR ASSEMBLY
ROOF OPENING PANEL SWITCH
SLIDE
TAN WIRE
TILT
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> ROOF OPENING PANEL MOTOR ASSEMBLY
