Mercury Sable IV (1999-2005) mirror open Wiring diagram
This page shows the only wiring diagram for the component.mirror open, which is found in the car Mercury Sable IV (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror open (1 of 1)
BLK WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
BRIGHT
CARGO SPACE LAMP (WAGON)
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DK GRN WIRE
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
FROM INTERIOR LAMPS RELAY (DIAGRAM 1 OF 2)
FRONT INTERIOR LAMPS
FUSE 26
HOT AT ALL TIMES
HOT IN RUN
LEFT VANITY MIRROR LAMP
LT GRN WIRE
LT GRN/ORG WIRE
LUGGAGE COMPARTMENT LAMP
LUGGAGE COMPARTMENT LID RELEASE SOLENOID (ON TRUNK LID LATCH MECHANISM)
MAP READING LAMPS
MIRROR OPEN
OFF
OFF ON
OFF ON ON
ON TAILGATE OPEN
ORG/ WIRE
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
PUDDLE LAMP RELAY
RED WIRE
RIGHT VANITY MIRROR LAMP
SEDAN
W/ ROOF OPENING PANEL
W/O ROOF OPENING PANEL
WAGON
WAGON SEDAN
WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> MIRROR OPEN
