Mercury Sable IV (1999-2005) luggage compartment lid release switch Wiring diagram
This page shows the only wiring diagram for the component.luggage compartment lid release switch, which is found in the car Mercury Sable IV (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram luggage compartment lid release switch (1 of 1)
BLK WIRE
CENTRAL JUNCTION BOX
FUSE 22 (UNDER LEFT SIDE OF DASH)
GENERIC ELECTRONIC MODULE (GEM) (UNDER LEFT SIDE OF DASH)
GRY/RED WIRE
HOT AT ALL TIMES
LUGGAGE COMPARTMENT LID RELEASE RELAY
LUGGAGE COMPARTMENT LID RELEASE SOLENOID (ON TRUNK LID LATCH MECHANISM)
LUGGAGE COMPARTMENT LID RELEASE SWITCH
ORG/LT GRN WIRE
PNK WIRE
PNK/ORG WIRE
RELAY CENTER BOX 2 (UNDER LEFT SIDE OF DASH)
VIO/YEL WIRE
W/ KEYLESS ENTRY
W/O KEYLESS ENTRY
YEL/LT GRN WIRE
Go to component -> Trunk release circuit -> LUGGAGE COMPARTMENT LID RELEASE SWITCH
