Mercury Sable IV (1999-2005) ckp pos sens - ckp pos sens + Wiring diagram

A/C SYSTEM BATTERY JUNCTION BOX (FRONT CENTER OF ENGINE COMPT, BEHIND RADIATOR) BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BRN/PNK WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) FUSE 25 CKP POS SENS - CKP POS SENS + COOLING FANS SYSTEM DIGITAL TRANS- MISSION RANGE (DTR) SENSOR DIGITAL TRANSMISSION RANGE (DTR) SENSOR (ON TOP OF TRANSMISSION HOUSING) DK BLU WIRE DK BLU/LT GRN WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE FUEL PUMP (ON FRONT SIDE OF FUEL TANK) FUEL PUMP RELAY FUEL SENDER MOD PROGRAMMING FUSE 16 FUSE 2 FUSE 37 GROUND GROUND IGN COIL A SHIFT SOL A LOW SPD FAN RLY GROUND IGN COIL B SHIFT SOL C GRY WIRE GRY/RED WIRE HIGH SPD FAN RLY EGR TACH HOT AT ALL TIMES HOT IN HOT IN RUN OR START IGNITION COIL (LEFT REAR OF ENGINE) IGNITION TRANSFORMER CAPACITOR (ATTACHED TO IGNITION COIL) INERTIA FUEL SHUT-OFF SWITCH (IN CARGO AREA, BEHIND RIGHT WHEELWELL) LT BLU WIRE LT BLU/BLK WIRE LT GRN/RED WIRE LT GRN/VIO WIRE LT GRN/YEL WIRE MAF SENS TFT SENS ECT SENS IAT SENS DRIVER INPUT DUAL PRESS SW FAN RLY CTRL NCA WIRE ORG DK GRN/ WIRE ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE PASSIVE ANTI-THEFT TRANSCEIVER MODULE (NEAR IGNITION SWITCH) PCM POWER RELAY PNK STARTER RLY WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/LT GRN WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR CORNER OF ENGINE COMPT, IN FIREWALL) RED WIRE RED/BLK WIRE SCP BUS (-) SCP BUS (+) RX, SIGNAL TX, SIGNAL STARTING SYSTEM TAN/LT BLU WIRE TAN/ORG WIRE TAN/RED WIRE TAN/YEL WIRE THEFT IND PSP SWITCH KNOCK SENS TO DTR SENSOR (DIAGRAM 4 OF 4) TO SPARK PLUGS TSS SENS VIO WIRE VIO/ORG WIRE VOLTAGE AT START WHT/BLK WIRE WHT/LT BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/LT GRN WIRE YEL/RED WIRE YEL/WHT WIRE
