Mercury Sable IV (1999-2005) cargo space lamp Wiring diagram
This page shows the only wiring diagram for the component.cargo space lamp, which is found in the car Mercury Sable IV (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cargo space lamp (1 of 1)
ANTI-THEFT LUGGAGE COMPARTMENT SWITCH
BLK WIRE
CARGO SPACE LAMP
CD CHANGER
DOCKING STATION
FUEL PUMP DRIVER MODULE
LEFT LICENSE PLATE LAMP RIGHT LICENSE PLATE LAMP
LEFT REAR PARK/ STOP LAMP
LEFT REAR PARK/ TURN LAMP
LEFT REAR SIDE LAMP
LEFT REAR TURN LAMP
LEFT REVERSING LAMP
LICENSE LAMPS
LIFTGATE LOCK CYLINDER SWITCH REAR WIPER MOTOR ASSEMBLY
LT GRN WIRE
LUGGAGE COMPARTMENT LID RELEASE SOLENOID
MICROPHONE
NCA WIRE
ORG/ WIRE
REAR CONTROL UNIT
REAR WINDOW DEFROST GRID
RIGHT REAR PARK/ STOP LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT REAR TURN LAMP RIGHT REAR SIDE LAMP
RIGHT REVERSING LAMP
SHIELD
Go to component -> Ground distribution circuit (3 of 3) -> CARGO SPACE LAMP
