Lamp outage circuit for Mercury Sable III (1995-1999)
Lamp outage circuit
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STOP LAMP IN
BLK WIRE
BLK/ORG WIRE
BRAKE ON/OFF (BOO) SWITCH (SIDE OF BRAKE PEDAL)
EXTERIOR LIGHTS SYSTEM (HMSL)
EXTERIOR LIGHTS SYSTEM (REAR PARK/STOP LAMPS AND REAR TURN LAMPS)
FUSE 14
FUSE 28
FUSE 31
HOT AT ALL TIMES
HOT IN PARK OR HEAD
HOT IN RUN
I/P FUSE PANEL
LAMP OUT WARNING MODULE (REAR LEFT SIDE OF CARGO AREA)
LT GRN WIRE
ORG/ WIRE
REAR MARKER IN REAR MARKER OUT
REAR PARK LMP IN REAR PARK LMP OUT PWR (RUN)
RED WIRE
RED/LT GRN WIRE
SEDAN ONLY
STOP LMP OUT HMSL IN HMSL OUT
TAN WIRE
WHT LT GRN/ WIRE
WHT WIRE
WHT/LT GRN WIRE
