Mercury Sable III (1995-1999) tilt up feed tilt down feed slid open feed slid closed feed Wiring diagram
This page shows the only wiring diagram for the component.tilt up feed tilt down feed slid open feed slid closed feed, which is found in the car Mercury Sable III (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tilt up feed tilt down feed slid open feed slid closed feed (1 of 1)
ACCESSORY DELAY RELAY
ACCESSORY DELAY RELAY CONTROL
BATTERY SAVER RELAY
BATTERY SAVER RELAY CONTROL
BLK WIRE
CLOSE OPEN
DK BLU WIRE
ENGINE COMPARTMENT FUSE/RELAY BOX
FUSE 27
GENERIC ELECTRONIC MODULE (UNDER I/P FUSE PANEL)
HOT AT ALL TIMES
HOT AT ALL TIMES POWER LOCKS FUSE
LT BLU WIRE
MOON- ROOF MOTOR
MOONROOF DRIVE ASSEMBLY (IN CENTER OF VEHICLE'S ROOF)
NCA WIRE
OVERHEAD CONSOLE I/P FUSE PANEL
PWR
RED WIRE
RED/YEL WIRE
SLIDE
SLIDE LIMIT SWITCH
SOLID STATE
TILT
TILT LIMIT SWITCH
TILT UP FEED TILT DOWN FEED SLID OPEN FEED SLID CLOSED FEED
UP DOWN
WHT WIRE
YEL/RED WIRE
Go to component -> Power top/sunroof circuits -> TILT UP FEED TILT DOWN FEED SLID OPEN FEED SLID CLOSED FEED
