Mercury Sable III (1995-1999) starter motor solenoid Wiring diagrams
This page contains all the electrical diagrams for the component. starter motor solenoid, in which he is found in the car Mercury Sable III (1995-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram starter motor solenoid (1 of 2)
BATTERY
BLK WIRE
BRN/PNK WIRE
CHARGING SYSTEM
ENGINE COMPARTMENT FUSE , RELAY BOX
FUSE 7
HOLD
HOT AT ALL TIMES IGNITION FUSE 3
HOT IN START
I/P FUSE PANEL
LT GRN WIRE
PNK WIRE
PPL
PULL- IN
RED WIRE
SENSOR (LEFT REAR OF ENG COMPT, ON TOP OF TRANSMISSION HOUSING) D/2
STARTER MOTOR SOLENOID
STARTER RELAY (IN ENGINE COMPARTMENT FUSE/ RELAY BOX)
TAN/RED WIRE
TRANSMISSION RANGE (TR)
WHT WIRE
Go to component -> 3.0l 24-valve, starting circuit -> STARTER MOTOR SOLENOID
Wiring diagram starter motor solenoid (2 of 2)
3.0 12-VALVE, 3.0L FFV ONLY
BATTERY
BLK WIRE
BLU WIRE
ENGINE COMPARTMENT FUSE/RELAY BOX ALTERNATOR FUSE 26
GENERATOR, VOLTAGE REGULATOR
GENERATOR/ BATTERY INDICATOR 510 OHMS
HOT IN RUN OR START I/P FUSE PANEL FUSE 11
INSTRUMENT CLUSTER
LT GRN WIRE
LT GRN/RED WIRE
MEGA FUSE (RIGHT SIDE OF ENGINE COMPT FUSE/RELAY BOX)
ORG/ WIRE
ORG/LT BLU WIRE
RED WIRE
STARTER MOTOR SOLENOID
WHT WIRE
WHT/BLK WIRE
WHT/YEL WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Charging circuit -> STARTER MOTOR SOLENOID
