Mercury Sable III (1995-1999) right radiator primary crash sensor left radiator primary crash sensor Wiring diagram
This page shows the only wiring diagram for the component.right radiator primary crash sensor left radiator primary crash sensor, which is found in the car Mercury Sable III (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right radiator primary crash sensor left radiator primary crash sensor (1 of 1)
* PIN SHORTING BAR IS ENGAGED WHEN MODULE CONNECTOR IS DISCONNECTED
10* 11* GND
2* DRVR AIR BAG 3* DRVR AIR BAG 4* 5* PASS AIR BAG
AIR BAG DIAGNOSTIC MONITOR (FRONT CENTER OF I/P)
AIR BAG IND
AIR BAG INDICATOR
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLOCK SPRING ASSEMBLY
DATA LINK
DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P)
DRIVER'S AIR BAG
GRY WIRE
GRY/ORG WIRE
GRY/WHT WIRE
HOT IN RUN I/P FUSE PANEL (LEFT SIDE OF I/P)
HOT IN RUN OR START FUSE 13 FUSE 11
INSTRUMENT CLUSTER
L CRASH SENS
LT BLU WIRE
LT BLU/ORG WIRE
LT BLU/WHT WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/YEL WIRE
PASS AIR BAG
PASSENGER'S AIR BAG
PNK PPL WIRE
PNK/BLK WIRE
PNK/WHT WIRE
PPL/LT BLU WIRE
PPL/ORG WIRE
PWR (BAT)
PWR RUN
R CRASH SENS
RIGHT RADIATOR PRIMARY CRASH SENSOR LEFT RADIATOR PRIMARY CRASH SENSOR
SHORTING BAR
TAN WIRE
TAN/BLK WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/LT GRN WIRE
YEL/WHT WIRE
