Mercury Sable III (1995-1999) prndl/ transmission control illumination ashtray lamp Wiring diagram
This page shows the only wiring diagram for the component.prndl/ transmission control illumination ashtray lamp, which is found in the car Mercury Sable III (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram prndl/ transmission control illumination ashtray lamp (1 of 1)
2/-
ACCESSORY DELAY RELAY
BATTERY SAVER RELAY
BATTERY SAVER RELAY CONTROL
BLK WIRE
BRN WIRE
CIGAR LIGHTER
DELAY RELAY CONTROL
DIMMING MODULE
DISTANCE TO EMPTY (DTE) MODULE
DK BLU WIRE
ENGINE COMPARTMENT FUSE/RELAY BOX (BEHIND RADIATOR)
FUSE 2 FUSE 18
FUSE 27
FUSE 33
GENERIC ELECTRONIC MODULE (ATTACHED TO I/P FUSE PANEL)
HEADLAMP SWITCH
HEADLAMP SWITCH BACKLIGHT
HEADLAMP SWITCH ILLUMINATION (W/ AUTOLAMPS/ DELAYED EXIT)
HOT AT ALL TIMES
I/P FUSE PANEL (LEFT SIDE OF I/P)
IGNITION SWITCH
ILLUM
INSTR ILLUM
INSTRUMENT CLUSTER
INTEGRATED CONTROL PANEL (RIGHT OF STEERING COLUMN)
LAMPS ON
LEFT MASTER DOOR LOCK SWITCH
LEFT REAR WINDOW SWITCH
LIFTGATE/ WIPER WASHER CONTROL (WAGON ONLY)
LOCK OFF
LT BLU WIRE
LT GRN WIRE
MASTER WINDOW CONTROL SWITCH
NCA WIRE
OFF HEAD
PARK
PARK LAMPS FUSE 20
POWER LOCKS FUSE 4
PPL
PRNDL/ TRANSMISSION CONTROL ILLUMINATION ASHTRAY LAMP
PULSE WIDTH DIMMING MODULE GROUND
RED WIRE
RIGHT FRONT WINDOW SWITCH
RIGHT MASTER DOOR LOCK SWITCH
RIGHT REAR WINDOW SWITCH
RUN WIRE
SOLID STATE
W/ AUTOLAMPS/ DELAYED EXIT
WHT WIRE
Go to component -> Instrument illumination circuit -> PRNDL/ TRANSMISSION CONTROL ILLUMINATION ASHTRAY LAMP
