Mercury Sable III (1995-1999) pnk/org or brn/wht wiring diagram
This page shows the only wiring diagram for the component.pnk/org or brn/wht, which is found in the car Mercury Sable III (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
pnk/org or brn/wht wiring diagram (1 of 1)
BLK WIRE
FUSE 26
GRY/RED WIRE
HOT AT ALL TIMES
I/P FUSE PANEL
LT GRN WIRE
PNK WIRE
PNK/ORG OR BRN/WHT WIRE
PNK/ORG WIRE
PNK/YEL WIRE
PPL/YEL WIRE
REMOTE ANTI-THEFT PERSONALITY (RAP) MODULE (BEHIND INTEGRATED CONTROL PANEL)
TRUNKLID AJAR SWITCH/ RELEASE SOLENOID (ON TRUNKLID LATCH MECHANISM)
TRUNKLID RELEASE RELAY (UNDER CENTER OF I/P)
TRUNKLID RELEASE SWITCH
W/ RAP
W/O RAP
YEL WIRE
Go to component -> Trunk release circuit -> PNK/ORG OR BRN/WHT WIRE
