Mercury Sable III (1995-1999) off flr/vnt vent flr norm def/flr max def Wiring diagram

883 OR 879 A/C CLUTCH CONTROL RELAY CONTROL SOLID STATE A/C CLUTCH FIELD COIL A/C HIGH PRESSURE SWITCH (FRONT CENTER OF ENGINE COMPARTMENT) A/C-HEATER SELECTOR SWITCH BLEND DOOR ACTUATOR (RIGHT SIDE OF A/C PLENUM BELOW I/P) BLK WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER MOTOR RELAY (IN ENGINE COMPARTMENT FUSE/RELAY BOX) BLOWER MOTOR SWITCH BLOWER RESISTOR (BEHIND RIGHT SIDE OF I/P) BRN WIRE BRN/ORG WIRE DK BLU WIRE DK GRN/WHT WIRE EDF RELAY ENGINE COMPARTMENT FUSE/RELAY BOX ENGINE COOLING FAN 1 ENGINE COOLING FAN 2 ENGINE COOLING FAN DROPPING RESISTOR (INSIDE RIGHT FRONT BUMPER) FUSE 13 FUSE 6 GRN WIRE GRY WIRE GRY/RED WIRE HEDF RELAY HOT AT ALL TIMES BLOWER MOTOR FUSE HOT IN RUN I/P FUSE PANEL LT BLU WIRE LT GRN WIRE LT GRN/PPL WIRE LT GRN/WHT WIRE OFF FLR/VNT VENT FLR NORM DEF/FLR MAX DEF OFF PAN/FLR PANEL FLR NORM DEF/FLR MAX ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/LT BLU OR DK GRN/WHT WIRE PNK/LT BLU WIRE PNK/ORG WIRE PNK/WHT WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (RIGHT REAR CORNER OF ENGINE COMPT) PPL RED WIRE RED/ORG WIRE RED/YEL WIRE SOLID STATE TEMPERATURE CONTROL POTENTIOMETER WHT WIRE YEL WIRE YEL/RED WIRE
