Mercury Sable III (1995-1999) liftgate wiper/washer control Wiring diagram
This page shows the only wiring diagram for the component.liftgate wiper/washer control, which is found in the car Mercury Sable III (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate wiper/washer control (1 of 1)
BLK WIRE
BRN WIRE
DK BLU WIRE
FUSE 19
HOT IN RUN OR ACC
I/P FUSE PANEL (UNDER LEFT CORNER OF INSTRUMENT CLUSTER)
INTERIOR LIGHTS SYSTEM (PULSE WIDTH DIMMING MODULE)
LIFTGATE WASHER PUMP MOTOR (RIGHT REAR OF VEHICLE, IN RESERVOIR)
LIFTGATE WIPER MOTOR
LIFTGATE WIPER/WASHER CONTROL
NCA WIRE
ORG/ WIRE
PARK SWITCH
SOLID STATE
SWITCH ILLUM.
WASHER SWITCH
WHT WIRE
WIPER SWITCH
Go to component -> Rear wiper/washer circuit -> LIFTGATE WIPER/WASHER CONTROL
