Mercury Sable III (1995-1999) license lamps Wiring diagrams
This page contains all the electrical diagrams for the component. license lamps, in which he is found in the car Mercury Sable III (1995-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram license lamps (1 of 2)
BLK WIRE
BRAKE ON/OFF (BOO) SWITCH (UPPER FRONT SIDE OF BRAKE PEDAL)
BRN WIRE
FUSE 28
HOT AT ALL TIMES
I/P FUSE PANEL
LEFT HI MOUNT STOP LAMP
LEFT REAR PARK/ STOP LAMP
LEFT REAR SIDE MARKER LAMP
LEFT REAR TURN LAMP
LICENSE LAMPS
LT GRN/ORG WIRE
LT GRN/RED WIRE
NCA WIRE
ORG/LT BLU WIRE
RED/LT GRN WIRE
RIGHT HI MOUNT STOP LAMP
RIGHT REAR PARK/ STOP LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT REAR TURN LAMP
Go to component -> Exterior lamps circuit, wagon without lamp out warning (2 of 2) -> LICENSE LAMPS
Wiring diagram license lamps (2 of 2)
3.4L SHO ONLY
ANTI- THEFT ALARM SWITCH
BLK WIRE
CARGO LAMP
CARGO LAMP RELAY
EXCEPT 3.4L SHO
FUEL PUMP/ FUEL GAUGE SENDER
LAMP OUT WARNING MODULE
LEFT BACKUP LAMP RIGHT BACKUP LAMP
LEFT LICENSE LAMP
LEFT REAR PARK/ STOP LAMP
LEFT REAR PARK/ STOP LAMP LEFT REAR TURN LAMP
LEFT REAR SIDE MARKER LAMP
LEFT REAR SIDE MARKER LAMP RIGHT REAR SIDE MARKER LAMP
LEFT REAR TURN LAMP
LICENSE LAMPS
LIFTGATE WIPER MOTOR
NCA WIRE
REAR WINDOW DEFROST GRID
REAR WINDOW DEFROST GRID FUEL PUMP/ FUEL GAUGE SENDER
RIGHT LICENSE LAMP
RIGHT REAR PARK/ STOP LAMP
RIGHT REAR SHOCK ACTUATOR LEFT REAR SHOCK ACTUATOR
RIGHT REAR SIDE MARKER LAMP
RIGHT REAR TURN LAMP
SABLE
SEDAN ONLY
SEMI-ACTIVE RIDE CONTROL (SARC) MODULE
TAURUS
TRUNKLID AJAR SWITCH/ RELEASE SOLENOID
TRUNKLID ANTI-THEFT SWITCH LAMP OUT WARNING MODULE
W/ RAP
WAGON ONLY
Go to component -> Ground distribution circuit (3 of 3) -> LICENSE LAMPS
