Mercury Sable III (1995-1999) lf height sensor rf height sensor Wiring diagram
This page shows the only wiring diagram for the component.lf height sensor rf height sensor, which is found in the car Mercury Sable III (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf height sensor rf height sensor (1 of 1)
1 2 3 4 5 6 7 8 9 10 21 22 23 24 25 26 PWR (BAT) VSS- VSS+ PWR (RUN)
ANTI-LOCK BRAKE CONTROL MODULE (BELOW BATTERY)
BLK WIRE
BLK/WHT WIRE
BRN/PNK WIRE
DATA LINK CONNECTOR (BELOW STEERING COLUMN)
DG GRN/YEL WIRE
DK GRN/YEL WIRE
ELECTRONIC POWER STEERING SYSTEM (ZF GEAR SOLENOID)
ENGINE COMPARTMENT FUSE/RELAY BOX
FUSE 14
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE PANEL
INSTRUMENT CLUSTER
LEFT FRONT FENDER)
LEFT FRONT SHOCK ACTUATOR (FRONT OF LEFT WHEEL WELL)
LEFT REAR SHOCK ACTUATOR (LEFT REAR OF VEHICLE, NEAR WHEEL WELL)
LF HEIGHT SENSOR RF HEIGHT SENSOR
LR SHOCK ACTUATOR GND ZF GEAR SOL FEED SENSOR PWR DLC
LT BLU/WHT WIRE
NCA WIRE
ORG/ WIRE
PNK/ORG WIRE
PPL/LT GRN WIRE
PPL/YEL WIRE
PWR (BAT)
RED/BLK WIRE
RF SHOCK ACTUATOR
RIGHT FRONT HEIGHT SENSOR (FRONT OF RIGHT FRONT WHEEL)
RIGHT FRONT SHOCK ACTUATOR (FRONT OF RIGHT WHEEL WELL)
RIGHT REAR SHOCK ACTUATOR (RIGHT REAR OF VEHICLE, NEAR WHEEL WELL)
RR SHOCK ACTUATOR LF SHOCK ACTUATOR
SEMI-ACTIVE RIDE CONTROL (SARC) MODULE (BEHIND RIGHT REAR SEAT)
SEMI-ACTIVE RIDE CONTROL FUSE
SENSOR GND GND
VSS
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WHT/RED WIRE
ZF GEAR SOL RTN
Go to component -> Electronic suspension circuit -> LF HEIGHT SENSOR RF HEIGHT SENSOR
