Mercury Sable III (1995-1999) left lumbar seat switch Wiring diagram
This page shows the only wiring diagram for the component.left lumbar seat switch, which is found in the car Mercury Sable III (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left lumbar seat switch (1 of 1)
BLK WIRE
ENGINE COMPARTMENT FUSE/RELAY BOX (BEHIND RADIATOR)
ENTIRE SEAT
FRONT OF SEAT
FWD RWD
HOT AT ALL TIMES
INFLATE DEFLATE
LEFT LUMBAR AIR BLADDER
LEFT LUMBAR SEAT SWITCH
LEFT POWER LUMBAR COMPRESSOR
LEFT SEAT CONTROL SWITCH
LEFT SEAT FRONT HEIGHT MOTOR
LEFT SEAT HORIZONTAL MOTOR
LEFT SEAT REAR HEIGHT MOTOR
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
POWER SEATS FUSE 6
REAR OF SEAT
RED WIRE
UP DN
WHT WIRE
YEL WIRE
Go to component -> Power & lumbar seat circuit -> LEFT LUMBAR SEAT SWITCH
