Mercury Sable III (1995-1999) left left rear license park/ lamp stop lamp Wiring diagram
This page shows the only wiring diagram for the component.left left rear license park/ lamp stop lamp, which is found in the car Mercury Sable III (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left left rear license park/ lamp stop lamp (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STOP LMP IN
BLK WIRE
BLK/ORG WIRE
BRAKE ON/OFF (BOO) SWITCH (UPPER FRONT SIDE OF BRAKE PEDAL)
BRN WIRE
FUSE 28
FUSE 31
HOT AT ALL TIMES
HOT IN RUN I/P FUSE PANEL FUSE 14
LAMP OUT WARNING MODULE (LEFT REAR SIDE OF CARGO AREA)
LEFT LEFT REAR LICENSE PARK/ LAMP STOP LAMP
LEFT REAR PARK/ STOP LAMP
LEFT REAR SIDE MARKER LAMP
LEFT REAR TURN LAMP
LT GRN WIRE
LT GRN/ORG WIRE
LT GRN/RED WIRE
OF TRUNK)
ORG/ WIRE
ORG/LT BLU WIRE
REAR PARK LMP IN REAR PARK LMP OUT PWR (ACC/RUN)
RED/LT GRN WIRE
RIGHT LICENSE LAMP
RIGHT REAR PARK/ STOP LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT RIGHT REAR TURN LAMP REAR SIDE MARKER LAMP
SABLE
STOP LMP OUT HMSL IN HMSL OUT REAR MARKER LMP IN REAR MARKER LMP OUT
TAN WIRE
TAURUS
WHT WIRE
WHT/LT GRN WIRE
Go to component -> Exterior lamps circuit, sedan with lamp out warning (2 of 2) -> LEFT LEFT REAR LICENSE PARK/ LAMP STOP LAMP
