Wiper/washer circuit for Mercury Mystique I (1994-2000)
Wiper/washer circuit
BLK WIRE
BLK/WHT WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CENTRAL TIMER MODULE (UNDER LEFT SIDE OF DASH)
FAST
FUSE 20
HOT AT ALL TIMES
HOT IN RUN AND START
IGNITION RELAY
IGNITION RELAY DIODE
NORM OFF INT
PARK
RUN WIRE
SHORTING BAR CONNECTOR 1 (BEHIND LEFT SIDE OF DASH)
SNGL WIPE
VARIABLE INTERMITTENT
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ VARIABLE INTERMITTENT WIPERS ONLY
WASH
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WIPER/ WASHER SWITCH
YEL/BLK WIRE
