Shift interlock circuit for Mercury Mystique I (1994-2000)

Shift interlock circuit

Get access

BLK WIRE BLK/WHT WIRE BLU WIRE CENTRAL JUNCTION BOX (CJB) (UNDER LEFT SIDE OF DASH) CRUISE CONTROL SYSTEM FUSE 23 FUSE 24 FUSE 30 FUSE 34 GEAR- SHIFT LEVER UNIT GRN WIRE HOT AT ALL TIMES HOT IN RUN ILLUM. LAMP SHIFT LOCK SOL. INSTRUMENT INTERFACE MODULE (BEHIND LEFT SIDE OF DASH) KEY REMOVAL INHIBIT SOLENOID (ON TOP OF STEERING COLUMN) NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/WHT WIRE ORG/YEL WIRE POWERTRAIN CONTROL MODULE (BEHIND POWER STEERING RESERVOIR) SHORTING BAR CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) TRANS CONTROL SWITCH (BELOW CENTER CONSOLE) VIO WIRE VIO/BLU WIRE VIO/WHT WIRE VOI/ WHT WIRE YEL WIRE
