Radio circuits, without amplifier for Mercury Mystique I (1994-2000)
Radio circuits, without amplifier
ANTENNA
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
FUSE 32
FUSE 34
GROUND POWER ANTENNA
HOT AT ALL TIMES
HOT IN RUN OR ACC
LEFT FRONT SPEAKER
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
POWER ANETNNA SYSTEM
POWER GROUND FUSED IGNITION ILLUM
RADIO
RIGHT FRONT SPEAKER LEFT REAR SPEAKER
RIGHT REAR SPEAKER
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED (OR WHT/BLK) WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
