Power window circuit for Mercury Mystique I (1994-2000)
Power window circuit
BLK WIRE
BLU WIRE
CENTER CONSOLE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DN UP
DRIVER POWER WINDOW SWITCH
FRONT DRIVER SIDE POWER WINDOW MOTOR
FRONT PASSENGER SIDE POWER WINDOW MOTOR
FUSE 21
GRN WIRE
GRY WIRE
HOT IN RUN OR START
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
ONE- TOUCH WINDOW RELAY (FRONT OF LEFT FRONT DOOR)
ORG/ WIRE
PASSENGER-SIDE POWER WINDOW SWITCH
REAR CUT- OFF SWITCH
RED WIRE
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
SOLID STATE
UP DN
UP UP ONE TOUCH DN
VIO WIRE
VIO/BLU WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
