10-way power seat circuit for Mercury Mystique I (1994-2000)

10-way power seat circuit

Get access

BLK WIRE BLU WIRE CENTRAL JUNCTION BOX DEFLATE DN UP FRONT HEIGHT MOTOR FWD REV FWD/ RWD MOTOR GRN WIRE HOT AT ALL TIMES FUSE 28 INFLATE LUMBAR COM- PRESSOR MOTOR (UNDER DRIVER'S SEAT BOTTOM) ORG/YEL WIRE POWER SEAT SWITCH PPL PPL REAR HEIGHT MOTOR RECLINER MOTOR (UNDER DRIVER'S SEAT BOTTOM) RED WIRE REV SEAT MOTOR ASSEMBLY (LEFT SIDE OF DRIVER'S SEAT) WHT WIRE YEL WIRE
