Power antenna circuit for Mercury Mystique I (1994-2000)
Power antenna circuit
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
FUSE 30
FUSE 32
FUSE 34
HOT AT ALL TIMES
HOT IN ACC OR RUN
HOT IN RUN
ORG/ WIRE
POWER ANTENNA MOTOR (RIGHT REAR OF LUGGAGE COMPARTMENT, BEHIND PANEL)
POWER ANTENNA TIMING UNIT (RIGHT REAR OF LUGGAGE COMPARTMENT, BEHIND PANEL)
RADIO
RED WIRE
SHORTING BAR CONNECTOR 4 (LEFT REAR OF LUGGAGE COMPARTMENT)
VIO/BLU WIRE
VIO/YEL WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
