Cooling fan circuit for Mercury Mystique I (1994-2000)
Cooling fan circuit
BATTERY JUNCTION BOX (BJB) (LEFT FRONT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
ENGINE COOLING FAN MOTOR
ENGINE COOLING FAN RELAY
ENGINE COOLING FAN RESISTOR (BELOW ENGINE COOLING FAN MOTOR)
FUSE 2
GRN WIRE
HIGH SPEED ENGINE COOLING FAN RELAY
HOT AT ALL TIMES
IF EQUIPPED AIR CONDITIONING SYSTEM
NCA WIRE
ORG/ WIRE
PCM POWER RELAY
RED WIRE
SECOND COOLING FAN MOTOR
SOLID STATE
W/AIR CONDITIONING
W/O AIR CONDITIONING
WHT WIRE
YEL WIRE
