A/c circuit for Mercury Mystique I (1994-2000)

A/C CLUTCH RELAY A/C CLUTCH SOLENOID (RIGHT FRONT SIDE OF ENGINE COMPARTMENT) A/C COMPRESSOR CLUTCH DIODE (RIGHT SIDE OF SECOND COOLING FAN MOTOR) A/C WIDE OPEN THROTTLE (WOT) RELAY AIR TEMPERATURE ACTUATOR (BEHIND CENTER DASH PANEL) BATTERY JUNCTION BOX (BJB) (LEFT FRONT SIDE OF ENGINE COMPARTMENT) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN/YEL WIRE CENTRALIZED JUNCTION BOX (CJB) (UNDER LEFT SIDE OF DASH PANEL) COOLING FANS SYSTEM FUSE 23 FUSE 37 GRN/YEL WIRE HEATER BLOWER MOTOR (BEHIND CENTER DASH PANEL) HEATER BLOWER RELAY HEATER BLOWER SERIES RESISTOR (BEHIND CENTER DASH PANEL) HEATER BLOWER SWITCH HEATER MODE SWITCH HOT AT ALL TIMES HOT IN RUN OR START LO HI NCA WIRE OFF PAN/FLR PANEL FLOOR A/C DEF/FLR MAX A/C DEFROST OFF PAN/FLR PANEL FLOOR DEF/FLR A/C DEFROST MAX A/C ORG/ WIRE RED WIRE SHORTING BAR CONNECTOR 1 (BEHIND LEFT SIDE DASH PANEL) SHORTING BAR CONNECTOR 3 (BEHIND RIGHT SIDE DASH PANEL) SOLID STATE TEMPERATURE DOOR VARIABLE RESISTOR VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/ORG WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

A/C COMPRESSOR CYCLING SWITCH (LEFT FRONT SIDE OF ENGINE COMPARTMENT) BATTERY JUNCTION BOX (BJB) (LEFT FRONT SIDE OF ENGINE COMPARTMENT) BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE COOLING FANS SYSTEM DUAL PRESSURE SWITCH (RIGHT FRONT SIDE OF ENGINE COMPARTMENT) ENGINE COOLING FAN MOTOR ENGINE COOLING FAN RELAY ENGINE COOLING FAN RESISTOR (BELOW ENGINE COOLING FAN MOTOR) FUSE 2 GRN WIRE GRN/YEL WIRE HIGH SPEED ENGINE COOLING FAN RELAY HOT AT ALL TIMES NCA WIRE ORG/ WIRE PCM POWER RELAY RED WIRE SECOND COOLING FAN MOTOR SOLID STATE VIO WIRE VIO/BLU WIRE VIO/ORG WIRE WHT WIRE YEL WIRE
