Mercury Mystique I (1994-2000) w/ higher option content Wiring diagram
This page shows the only wiring diagram for the component.w/ higher option content, which is found in the car Mercury Mystique I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ higher option content (1 of 1)
AIR TEMPERTURE ACTUATOR
BATTERY JUNCTION BOX
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX
DAYTIME RUNNING LAMPS RELAY
DRIVER'S DOOR
DRIVER'S DOOR LOCK/ UNLOCK SWITCH
FROM IGNITION RELAY DIAGRAM (2 OF 4)
FUSE 20
FUSE 21
FUSE 23
GEARSHIFT LEVER UNIT
HEATER MODE SWITCH
MOONROOF UNIT
NCA WIRE
ONE-TOUCH WINDOW RELAY
ORG/ WIRE
OVERSPEED WARNING MODULE
PARK/ NEUTRAL POSITION SWITCH
PASSENGER'S DOOR LOCK/ UNLOCK SWITCH
PASSENGER-SIDE POWER WINDOW SWITCH
POWER WINDOW SWITCH- DRIVER
SPEED CONTROL MODULE
TURN SIGNAL SWITCH
VIO WIRE
W/ DRL
W/ HIGHER OPTION CONTENT
W/O DRL
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> W/ HIGHER OPTION CONTENT
