Mercury Mystique I (1994-2000) right rear door lock/ unlock motor right rear power window switch Wiring diagram
This page shows the only wiring diagram for the component.right rear door lock/ unlock motor right rear power window switch, which is found in the car Mercury Mystique I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear door lock/ unlock motor right rear power window switch (1 of 1)
A/T
ANTI-THEFT/ CENTRAL LOCKING MODULE
BLK WIRE
BLK/GRN WIRE
BLU WIRE
DATA LINK CONNECTOR
DRIVER'S DOOR LOCK/ UNLOCK SWITCH
DRIVER'S POWER WINDOW SWITCH
DRIVER'S SIDE DOOR LOCK MOTOR
DRIVER'S SIDE MIRROR MOTOR
FRONT INTERIOR LAMP
GEARSHIFT LEVER UNIT
INHIBIT SWITCH
LEFT DOOR KEY CYLINDER LAMP
LEFT FRONT DOOR AJAR SWITCH
LEFT FRONT DOOR AJAR SWITCH LEFT REAR DOOR AJAR SWITCH
LEFT REAR DOOR LOCK MOTOR
LEFT REAR POWER WINDOW SWITCH
LEFT VANITY MIRROR LAMP
M/T
MOONROOF UNIT
ONE-TOUCH WINDOW RELAY
ORG/ WIRE
PASSENGER'S DOOR LOCK/ UNLOCK SWITCH PASSENGER'S SIDE MIRROR MOTOR
PASSENGER'S FRONT DOOR LOCK SWITCH
PASSENGER'S FRONT DOOR LOCK/ UNLOCK SWITCH
PASSENGER'S SIDE DOOR AJAR SWITCH
PASSENGER'S SIDE DOOR LOCK MOTOR
PASSENGER'S SIDE DOOR LOCK/ UNLOCK SWITCH RIGHT DOOR KEY CYLINDER LAMP
POWER LOCK CONTROL RELAY
POWER SEAT SWITCH
REAR INTERIOR LAMP
RIGHT DOOR KEY CYLINDER LAMP
RIGHT REAR DOOR AJAR SWITCH
RIGHT REAR DOOR LOCK MOTOR
RIGHT REAR DOOR LOCK/ UNLOCK MOTOR RIGHT REAR POWER WINDOW SWITCH
RIGHT VANITY MIRROR LAMP
SEAT BELT BUCKLE SWITCH
TRANSMISSION RANGE SWITCH
W/ ANTI- THEFT
W/ POWER WINDOWS
W/O ANTI- THEFT
W/O POWER WINDOWS
WHT WIRE
Go to component -> Ground distribution circuit (2 of 3) -> RIGHT REAR DOOR LOCK/ UNLOCK MOTOR RIGHT REAR POWER WINDOW SWITCH
