Mercury Mystique I (1994-2000) power mirror adjust switch Wiring diagrams
This page contains all the electrical diagrams for the component. power mirror adjust switch, in which he is found in the car Mercury Mystique I (1994-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power mirror adjust switch (1 of 2)
ANTI-THEFT/ CENTRAL LOCKING MODULE
BATTERY JUNCTION BOX
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX
CLOCK
DRIVER'S DOOR LOCK/ UNLOCK SWITCH
DRIVER'S SIDE FRONT DOOR ENTRY LAMP
DRIVERS DOOR LOCK MOTOR
FROM FUSE 25 (DIAGRAM 1 OF 4)
FROM FUSE 28 (DIAGRAM 1 OF 4)
FROM IGNITION RELAY DIAGRAM (2 OF 4)
FRONT INTERIOR LAMP
FUSE 34
FUSE 4
GEARSHIFT LEVER UNIT
GRN WIRE
IGNITION TRANSFORMER
IGNITION TRANSFORMER CAPACITOR
LEFT FRONT FOOTWELL LAMP
LEFT VANITY MIRROR LAMP
LUGGAGE COMPARTMENT LAMP
NCA WIRE
ORG/ WIRE
PANIC ALARM HEADLAMP RELAY
PANIC ALARM STOP LAMP RELAY
PASSENGER'S DOOR LOCK/ UNLOCK SWITCH
PASSENGER'S SIDE FRONT DOOR ENTRY LAMP
PASSENGERS DOOR LOCK MOTOR
PCM POWER RELAY
POWER ANTENNA TIMING UNIT
POWER MIRROR ADJUST SWITCH
RADIO
REAR INTERIOR LAMP
RIGHT FRONT FOOTWELL LAMP
RIGHT REAR DOOR LOCK MOTOR LEFT REAR DOOR LOCK MOTOR
RIGHT VANITY MIRROR LAMP
VIO WIRE
W/ ANTI- THEFT
WHT WIRE
YEL WIRE
ZETEC-VCT
Go to component -> Power distribution circuit (3 of 4) -> POWER MIRROR ADJUST SWITCH
Wiring diagram power mirror adjust switch (2 of 2)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DEFOGGER SYSTEM
DOWN
FUSE 34
GRN WIRE
HOT AT ALL TIMES
LEFT
LEFT POWER/ HEATED MIRROR
LEFT RIGHT
ORG/ WIRE
POWER MIRROR ADJUST SWITCH
RED WIRE
RIGHT
RIGHT LEFT
RIGHT POWER/ HEATED MIRROR LEFT/ RIGHT UP/ DOWN
SHORTING BAR CONN 1
UP DIRECTIONAL CONTROL SWITCH
UP/ LEFT/ RIGHT DOWN
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power mirror circuit -> POWER MIRROR ADJUST SWITCH
