Mercury Mystique I (1994-2000) passenger power window switch Wiring diagram
This page shows the only wiring diagram for the component.passenger power window switch, which is found in the car Mercury Mystique I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger power window switch (1 of 1)
2 4 (MYSTIQUE) (CONTOUR)
3 5 (MYSTIQUE) (CONTOUR)
BATTERY JUNCTION BOX
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
CENTRAL JUNCTION BOX
CENTRAL TIMER MODULE
CLOCK
DRIVER DOOR LOCK/ UNLOCK SWITCH
DRIVER POWER WINDOW SWITCH
FRONT CIGAR LIGHTER
FUSE 10
FUSE 21
FUSE 23
FUSE 31
GEARSHIFT LEVER UNIT
HEAD
HEADLAMP SWITCH PANEL ILLUMINATION
HEATER PANEL ILLUMINATION LAMP
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUMINATION DIMMER CONTROL
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT REAR POWER WINDOW SWITCH
LIGHT SWITCH
NCA WIRE
ORG/ WIRE
ORG/WHT WIRE
PARK HEAD OFF
PARK OFF
PASSENGER DOOR LOCK/ UNLOCK SWITCH
PASSENGER POWER WINDOW SWITCH
RADIO
REAR WINDOW CUT-OFF SWITCH
REAR WINDOW DEFROST SWITCH
RED WIRE
RED/GRN WIRE
RIGHT REAR POWER WINDOW SWITCH
SHORTING BAR CONNECTOR 2
SHORTING BAR CONNECTOR 3
SHORTING BAR CONNECTOR 5
VIO WIRE
VIO/BLU WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT GRN/ WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN (OR WHT/RED) WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Instrument illumination circuit -> PASSENGER POWER WINDOW SWITCH
