Mercury Mystique I (1994-2000) off pan/flr panel floor a/c def/flr max a/c defrost Wiring diagram
This page shows the only wiring diagram for the component.off pan/flr panel floor a/c def/flr max a/c defrost, which is found in the car Mercury Mystique I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off pan/flr panel floor a/c def/flr max a/c defrost (1 of 1)
A/C CLUTCH RELAY
A/C CLUTCH SOLENOID (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
A/C COMPRESSOR CLUTCH DIODE (RIGHT SIDE OF SECOND COOLING FAN MOTOR)
A/C WIDE OPEN THROTTLE (WOT) RELAY
AIR TEMPERATURE ACTUATOR (BEHIND CENTER DASH PANEL)
BATTERY JUNCTION BOX (BJB) (LEFT FRONT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN/YEL WIRE
CENTRALIZED JUNCTION BOX (CJB) (UNDER LEFT SIDE OF DASH PANEL)
COOLING FANS SYSTEM
FUSE 23
FUSE 37
GRN/YEL WIRE
HEATER BLOWER MOTOR (BEHIND CENTER DASH PANEL)
HEATER BLOWER RELAY
HEATER BLOWER SERIES RESISTOR (BEHIND CENTER DASH PANEL)
HEATER BLOWER SWITCH
HEATER MODE SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
LO HI
NCA WIRE
OFF PAN/FLR PANEL FLOOR A/C DEF/FLR MAX A/C DEFROST
OFF PAN/FLR PANEL FLOOR DEF/FLR A/C DEFROST MAX A/C
ORG/ WIRE
RED WIRE
SHORTING BAR CONNECTOR 1 (BEHIND LEFT SIDE DASH PANEL)
SHORTING BAR CONNECTOR 3 (BEHIND RIGHT SIDE DASH PANEL)
SOLID STATE
TEMPERATURE DOOR VARIABLE RESISTOR
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> A/c circuit (1 of 2) -> OFF PAN/FLR PANEL FLOOR A/C DEF/FLR MAX A/C DEFROST
