Mercury Mystique I (1994-2000) left rear lamp assembly rear park lamp Wiring diagram
This page shows the only wiring diagram for the component.left rear lamp assembly rear park lamp, which is found in the car Mercury Mystique I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear lamp assembly rear park lamp (1 of 1)
ANTI-THEFT SYSTEM (PANIC ALARM STOP LAMP RELAY)
BATTERY JUNCTION BOX (LEFT FRONT CORNER OF ENGINE COMPT)
BLK WIRE
BLK/ BLU WIRE
BLU RED/ WIRE
BLU WIRE
BLU/ BLK WIRE
BLU/ WHT WIRE
BLU/ YEL WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
FRONT TURN LAMP FRONT PARK LAMP
FUSE 10
FUSE 12
FUSE 23
FUSE 24
FUSE 31
FUSE 33
FUSE 35
HAZARD SWITCHES
HEAD
HEADLAMP SWITCH
HI MOUNT STOP LAMP
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
LEFT FRONT PARK/ TURN LAMP FRONT TURN LAMP
LEFT LICENSE LAMP
LEFT REAR LAMP ASSEMBLY REAR PARK LAMP
LEFT RIGHT
LEFT TURN INDI- CATOR RIGHT TURN INDI- CATOR
MAIN LIGHT SWITCH
NCA WIRE
NORMAL HAZARD
OFF
OFF OFF
OFF PARK
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/GRN WIRE
ORG/WHT WIRE
ORG/YEL WIRE
REAR PARK LAMP REAR TURN/ STOP LAMP
RED GRN/ WIRE
RED WIRE
RED/ BLU WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT PARK/ TURN LAMP FRONT PARK LAMP
RIGHT LICENSE LAMP
RIGHT REAR LAMP ASSEMBLY REAR TURN/ STOP LAMP
SHORTING BAR CONNECTOR 1
SHORTING BAR CONNECTOR 3
SHORTING BAR CONNECTOR 4
STOP LAMP SWITCH (TOP OF BRAKE PEDAL BRACKET)
TURN SIGNAL RELAY
TURN SIGNAL SWITCH
TURN SIGNAL SWITCHES
VIO/BLU WIRE
YEL BLU/ WIRE
YEL RED/ WIRE
Go to component -> Exterior lamps circuit -> LEFT REAR LAMP ASSEMBLY REAR PARK LAMP
