Mercury Mystique I (1994-2000) illum. lamp shift lock sol. Wiring diagram
This page shows the only wiring diagram for the component.illum. lamp shift lock sol., which is found in the car Mercury Mystique I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram illum. lamp shift lock sol. (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (UNDER LEFT SIDE OF DASH)
CRUISE CONTROL SYSTEM
FUSE 23
FUSE 24
FUSE 30
FUSE 34
GEAR- SHIFT LEVER UNIT
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN
ILLUM. LAMP SHIFT LOCK SOL.
INSTRUMENT INTERFACE MODULE (BEHIND LEFT SIDE OF DASH)
KEY REMOVAL INHIBIT SOLENOID (ON TOP OF STEERING COLUMN)
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/WHT WIRE
ORG/YEL WIRE
POWERTRAIN CONTROL MODULE (BEHIND POWER STEERING RESERVOIR)
SHORTING BAR CONNECTOR 1 (BEHIND LEFT SIDE OF DASH)
STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
TRANS CONTROL SWITCH (BELOW CENTER CONSOLE)
VIO WIRE
VIO/BLU WIRE
VIO/WHT WIRE
VOI/
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> ILLUM. LAMP SHIFT LOCK SOL.
