Mercury Mystique I (1994-2000) dual pressure switch Wiring diagram
This page shows the only wiring diagram for the component.dual pressure switch, which is found in the car Mercury Mystique I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dual pressure switch (1 of 1)
A/C COMPRESSOR CLUTCH DIODE A/C CLUTCH SOLENOID
ABS CONTROL MODULE
BATTERY
BATTERY JUNCTION BOX
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BUSBAR
CLOCK- SPRING
DAYTIME RUNNING LAMPS RELAY A/C CLUTCH RELAY
DUAL PRESSURE SWITCH
ENGINE COOLING FAN RELAY LO-BEAM HEADLAMP RELAY
HI-BEAM HEADLAMP RELAY
LEFT FRONT PARK/ TURN LAMP
LEFT HEADLAMP
LOW COOLANT LEVEL SWITCH RIGHT FOG LAMP
MASS AIR FLOW SENSOR
ORG/ WIRE
OVERSPEED WARNING MODULE LEFT FOG LAMP
PCM POWER RELAY
POWERTRAIN CONTROL MODULE
RIGHT FRONT PARK/ TURN LAMP
RIGHT HEADLAMP
SECOND COOLING FAN MOTOR ENGINE COOLING FAN MOTOR
SPEED CONTROL MODULE
VEHICLE SPEED SENSOR
W/ A/C
W/ ABS
W/ SPEED CONTROL
W/O A/C
W/O ABS
W/O SPEED CONTROL
WHT WIRE
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> DUAL PRESSURE SWITCH
