Mercury Mystique I (1994-2000) central junction box Wiring diagrams
This page contains all the electrical diagrams for the component. central junction box, in which he is found in the car Mercury Mystique I (1994-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram central junction box (11 of 12)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX
DEFLATE
DN UP
FRONT HEIGHT MOTOR
FWD REV
FWD/ RWD MOTOR
GRN WIRE
HOT AT ALL TIMES FUSE 28
INFLATE
LUMBAR COM- PRESSOR MOTOR (UNDER DRIVER'S SEAT BOTTOM)
ORG/YEL WIRE
POWER SEAT SWITCH
PPL PPL
REAR HEIGHT MOTOR
RECLINER MOTOR (UNDER DRIVER'S SEAT BOTTOM)
RED WIRE
REV
SEAT MOTOR ASSEMBLY (LEFT SIDE OF DRIVER'S SEAT)
WHT WIRE
YEL WIRE
Go to component -> 10-way power seat circuit -> CENTRAL JUNCTION BOX
Wiring diagram central junction box (12 of 12)
Go to component -> 6-way power seat circuit -> CENTRAL JUNCTION BOX
