Power top/sunroof circuit, with medium overhead console for Mercury Mountaineer III (2005-2010)

Power top/sunroof circuit, with medium overhead console

Get access

1 2 3 4 5 6 7 8 9 10 GND ACCESSORY DELAY RELAY BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BRN WIRE CLOSE DEL ACC FUSE 1 FUSE 5 HOT AT ALL TIMES OPEN B+ RED WIRE ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF) ROOF OPENING PANEL SWITCH SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) TAN WIRE VIO WIRE VIO/BRN WIRE WHT WIRE YEL WIRE YEL/ORG WIRE
