Driver power seat circuit, with 10-way power seat for Mercury Mountaineer III (2005-2010)
Driver power seat circuit, with 10-way power seat
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER SEAT LUMBAR COMPRESSOR MOTOR (IN DRIVER'S SEAT BACK)
DRIVER SEAT RECLINER MOTOR (RIGHT SIDE OF DRIVER'S SEAT BACK)
ENTIRE SEAT
FORWARD/REARWARD
FRONT OF SEAT
FUSE 14
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT POWER SEAT SWITCH
LUMBAR OF SEAT
REAR OF SEAT
RECLINE OF SEAT
RED WIRE
UP/DOWN FRONT
UP/DOWN REAR LEFT POWER SEAT MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
VIO WIRE
WHT WIRE
YEL WIRE
