Trailer tow circuit, with heavy duty for Mercury Mountaineer III (2005-2010)
Trailer tow circuit, with heavy duty
BATTERY CHARGE TRAILER TOW RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BOO
BRN WIRE
CONTROL
FUSE 16 SENSE
FUSE 17 FUSE 13
FUSE 25
FUSE 7
GRN WIRE
GRY WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
HOT IN RUN OR ACC
HSD
NCA WIRE
ORG/ WIRE
PARK LAMP RELAY
PWR
RED WIRE
REVERSE LAMP RELAY
TRAIL
TRAILER ELECTRONIC BRAKE CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
TRAILER TOW CONNECTOR (AT REAR OF VEHICLE, BELOW BUMPER)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
