Mercury Mountaineer III (2005-2010) roof opening panel switch Wiring diagrams
This page contains all the electrical diagrams for the component. roof opening panel switch, in which he is found in the car Mercury Mountaineer III (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram roof opening panel switch (1 of 3)
6-WAY 10-WAY
AUDIO CONTROL SWITCH
AUTOLAMP/ SUNLOAD SENSOR
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BRAKE SHIFT INTERLOCK
CLOCKSPRING (AT TOP OF STEERING COLUMN)
CONTROL MODULE
DRIVER LEFT SEAT POWER MODULE SEAT (DSM) SWITCH
DRIVER SAFETY BELT BUCKLE SWITCH
DRIVER SEAT MODULE (DSM)
DRIVER SIDE DOOR LOCK SWITCH
DRIVER SIDE EXTERIOR KEYPAD REAR VIEW SWITCH ASSEMBLY MIRROR
DRIVER SIDE REAR DOOR AJAR SWITCH
ELECTRONIC COMPASS
EXCEPT EXPLORER EXPLORER
EXPLORER, MOUNTAINEER
EXTERIOR REAR VIEW MIRROR SWITCH
FRONT INTERIOR/ HOMELINK MAP LAMPS ASSEMBLY MODULE
FRONT INTERIOR/ MAP LAMPS ASSEMBLY
GRN WIRE
HEATED SEAT/ WINDSHIELD SWITCH
HVAC MODULE (DATC)
INSTRUMENT CLUSTER (IC)
LEFT FRONT SEAT BACK HEATER
LEFT LEFT (SPORT TRAC) POWER POWER CARGO SEAT SEAT LAMP SWITCH SWITCH ASSEMBLY
LEFT SEAT TRACK POSITION SENSOR
LIFTGATE AJAR SWITCH
LIFTGATE GLASS RELEASE SWITCH
MAIN LIGHT SWITCH
MASTER DRIVER WINDOW SIDE FRONT ADJUST DOOR AJAR SWITCH SWITCH
MEMORY SET SWITCH
MULTI- FUNCTION SWITCH
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM (OCSM) MODULE
ORG/ WIRE
PARKING AID MODULE (PAM)
PASSENGER SAFETY BELT BUCKLE SWITCH
PASSENGER SIDE REAR PARK DOOR AJAR BRAKE SWITCH SWITCH
RIGHT VANITY MIRROR LAMP
ROOF OPENING PANEL SWITCH
STEERING WHEEL/ SPEED CONTROL SWITCH
VIO WIRE
W/O MEMORY
Go to component -> Ground distribution circuit (2 of 4) -> ROOF OPENING PANEL SWITCH
Wiring diagram roof opening panel switch (2 of 3)
1 2 3 4 5 6 7 8 9 10 GND
ACCESSORY DELAY RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BRN WIRE
CLOSE
DEL ACC
FUSE 1
FUSE 5
HOT AT ALL TIMES
OPEN B+
RED WIRE
ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF)
ROOF OPENING PANEL SWITCH
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TAN WIRE
VIO WIRE
VIO/BRN WIRE
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power top/sunroof circuit, with medium overhead console -> ROOF OPENING PANEL SWITCH
Wiring diagram roof opening panel switch (3 of 3)
ACCESSORY DELAY RELAY
BLK WIRE
BRN WIRE
CLOSE
FUSE 1
FUSE 5
GND SW COMMON DEL ACC
HOT AT ALL TIMES
OPEN B+
ORG/ WIRE
RED WIRE
ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF)
ROOF OPENING PANEL SWITCH
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power top/sunroof circuit, without medium overhead console -> ROOF OPENING PANEL SWITCH
