Mercury Mountaineer III (2005-2010) passenger roof opening side panel door module lock switch Wiring diagram
This page shows the only wiring diagram for the component.passenger roof opening side panel door module lock switch, which is found in the car Mercury Mountaineer III (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger roof opening side panel door module lock switch (1 of 1)
A/C CLUTCH RELAY
ACC/ DELAY RELAY
ACCESSORY PROTOCOL INTERFACE MODULE (APIM) (LATE PRODUCTION)
AUTO- DIMMING INTERIOR MIRROR UNIT
AUXILIARY RELAY BOX 1 (RIGHT REAR OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT BREAKER 1 CONTROL
DEL
DRIVER MASTER SIDE WINDOW DOOR ADJUST LOCK SWITCH SWITCH
DRIVER SEAT MODULE
EXTERIOR REAR VIEW MIRROR SWITCH
FOG LAMP RELAY
FROM FUSE 1, BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 6)
FROM FUSE 25 BATTERY FUSE 26 JUNCTION BOX (BJB) (DIAGRAM 1 OF 6)
FRONT WIPER RELAY
FUSE 1
FUSE 20
FUSE 27
FUSE 28
FUSE 29
FUSE 31 FUSE 30
FUSE 32
FUSE 34
FUSE 35
FUSE 36
FUSE 41 FUSE 9
FUSE 5
FUSE 8
GRN WIRE
GRY WIRE
HEATED SEAT/ WINDSHIELD SWITCH
HSD
LEFT HEADLAMP
LEFT HEATED SEAT RELAY
LEFT HEATED WINDSHIELD RELAY
LEFT POWER ADJUSTABLE SEAT SWITCH PEDAL SWITCH
LOGIC
NEUTRAL CONTROL TOW MODULE INDICATOR
ORG/ WIRE
PASSENGER ROOF OPENING SIDE PANEL DOOR MODULE LOCK SWITCH
REAR CONSOLE POWER POINT
REAR ENTERTAINMENT MODULE (RETM)
REAR WIPER MODULE
RED WIRE
RIGHT HEADLAMP
RIGHT HEATED SEAT RELAY
RIGHT HEATED WINDSHIELD RELAY
ROOF OPENING PANEL MODULE
SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TRANSMISSION CONTROL MODULE (TCM)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> PASSENGER ROOF OPENING SIDE PANEL DOOR MODULE LOCK SWITCH
