Mercury Mountaineer III (2005-2010) ins ill pot- Wiring diagram
This page shows the only wiring diagram for the component.ins ill pot-, which is found in the car Mercury Mountaineer III (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ins ill pot- (1 of 1)
15 16 MS CAN + MS CAN -
4 5 MS CAN + MS CAN -
ADJUSTABLE PEDAL SWITCH
AUDIO CONTROL MODULE
AUDIO/ CLIMATE CONTROL SWITCH
AUTOLAMP/ SUNLOAD SENSOR (BEHIND GLOVE BOX)
AUXILIARY CLIMATE CONTROL ASSEMBLY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRAKE SHIFT INTERLOCK (UNDER CENTER FLOOR CONSOLE)
BRN WIRE
BRN/WHT WIRE
CLIMATE CONTROL ASSEMBLY
CLOCKSPRING (AT TOP OF STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CTRL SOLID STATE
DEFEAT
DIMMING
DK DIM
DOME
DRIVER SIDE DOOR LOCK SWITCH
FOG 6 10
FOG IND 5 9 4 AUTO OFF PARK
FOUR WHEEL DRIVE SWITCH
FUSE 23
FUSE 5
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEATED SEAT/ WINDSHIELD SWITCH
HOT AT ALL TIMES
HOT W/ ACC/DELAY RELAY ENERGIZED
HVAC MODULE (DATC) (BEHIND LOWER CENTER OF DASH)
ILLUM
ILLUMINATION DIMMER SWITCH
INS ILL POT-
INSTRUMENT CLUSTER
LOW 3 2
MAIN LIGHT SWITCH
MEMORY SET SWITCH
MS CAN CAN INSTRUMENT ILLUMINATION
ORG/ WIRE
PARK BRAKE SWITCH (BEHIND TOP OF LEFT KICK PANEL)
PASSENGER SIDE DOOR LOCK SWITCH
SENSE
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
STEERING WHEEL/ SPEED CONTROL SWITCH
TRACTION CONTROL SWITCH MESSAGE CENTER SWITCH DIMMER
UNDEFEATED
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> INS ILL POT-
