Mercury Mountaineer III (2005-2010) htr 12 ctrl tss sens sig oss sens sig iss sens sig Wiring diagram
This page shows the only wiring diagram for the component.htr 12 ctrl tss sens sig oss sens sig iss sens sig, which is found in the car Mercury Mountaineer III (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram htr 12 ctrl tss sens sig oss sens sig iss sens sig (1 of 1)
29 37 OD CANCEL POWER HOLD
34 45 44 PCC CTRL SHIFT SOL D CTRL SHIFT SOL C CTRL
46 43 42 TCC SOL CTRL SHIFT SOL B CTRL SHIFT SOL A CTRL
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRAKE SHIFT INTERLOCK (UNDER CENTER FLOOR CONSOLE)
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
ENGINE CONTROLS SYSTEM
FUSE 20
FUSE 38 FUSE 42
FUSE 7
GRN WIRE
GRN/BRN WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEATED HEATED OXYGEN SENSOR OXYGEN SENSOR
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
HTR 12 CTRL TSS SENS SIG OSS SENS SIG ISS SENS SIG
HTR 22 CTRL
INTERMEDIATE SHAFT SPEED (ISS) SENSOR (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION)
OUTPUT SHAFT SPEED (OSS) SENSOR (LEFT REAR OF AUTOMATIC TRANSMISSION)
OVER DRIVE SWITCH
PCA CTRL
PCA CTRL SIGRTN TFT
PCB CTRL TFT SENS INPUT
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE ENGINE)
SIG RTN
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TCC SOL CTRL SHIFT SOL B CTRL SHIFT SOL A CTRL
TRANSMISSION ASSEMBLY
TURBINE SHAFT SPEED (TSS) SENSOR (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION)
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> 4.0l, a/t circuit -> HTR 12 CTRL TSS SENS SIG OSS SENS SIG ISS SENS SIG
