Mercury Mountaineer III (2005-2010) fuel pump diode Wiring diagrams
This page contains all the electrical diagrams for the component. fuel pump diode, in which he is found in the car Mercury Mountaineer III (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuel pump diode (1 of 3)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
FUEL PUMP DIODE
FUSE 27
GND 2
GRN WIRE
GRN/ORG WIRE
H CAN+
HOT AT ALL TIMES
HOT IN START OR RUN FUSE 9
HS CAN+
PCM RLY TRSW-PN
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE)
RED WIRE
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TRANSMISSION CONTROL MODULE (RIGHT SIDE OF TRANSMISSION)
TRSW-PN
WHT WIRE
WHT/BLU WIRE
Go to component -> 4.6l, a/t circuit -> FUEL PUMP DIODE
Wiring diagram fuel pump diode (2 of 3)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUDIO CONTROL MODULE (ACM)
AUTO- DIMMING INTERIOR MIRROR UNIT
BATTERY CHARGE TRAILER TOW RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CONTROL MODULE
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (4.0L)
ELECTRONIC COMPASS
EXPLORER
FOUR WHEEL DRIVE SWITCH
FROM FUSE 17 SMART JUNCTION FUSE 19 BOX (SJB) (DIAGRAM 4 OF 6)
FROM FUSE 22 SMART JUNCTION BOX (SJB) (DIAGRAM 3 OF 6)
FROM RUN START/RELAY SMART JUNCTION FUSE 9 BOX (SJB) (DIAGRAM 4 OF 5)
FRONT AUXILIARY CLIMATE CONTROL ASSEMBLY
FRONT WIPER RELAY
FUEL PUMP DIODE
FUSE 10
FUSE 11
FUSE 12
FUSE 18
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HEATED SEAT/ WINDSHIELD SWITCH
HSD RIGHT FRONT TURN
LEFT HEATED SEAT RELAY
LOGIC
MOUNTAINEER (IN DASH PANEL TO ENGINE HARNESS, NEAR BREAKOUT
MOUNTAINEER EXPLORER
ORG/ WIRE
PARKING AID MODULE (PAM)
REAR BLEND DOOR ACTUATOR
REAR WIPER MODULE
RED WIRE
RIGHT FRONT PARK/TURN LAMP
RIGHT HEATED SEAT RELAY
RIGHT REAR PARK/STOP TURN LAMP
RIGHT REAR STOP/ TURN
RIGHT REAR TURN LAMP
RIGHT REPEATER LAMP
RUN/ACC
SENSE
SMR/ SMCS
START DIODE
TO IGNITION SWITCH (DIAGRAM 6 OF 6)
TO SPLICE
TRACTION CONTROL SWITCH
TRANSMISSION CONTROL POWERTRAIN MODULE CONTROL MODULE (TCM) (PCM) (4.6L)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> FUEL PUMP DIODE
Wiring diagram fuel pump diode (3 of 3)
ACCELERATOR PEDAL POSITION SENSOR (UNDER LEFT SIDE OF DASH)
ACPT SCCS
AIR CONDITIONING SYSTEM
BATTERY JUNCTION BOX (BJB)
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BPS CSGND HS CAN+ FPC VAPVNT ACCR ACCS
BRN/GRN WIRE
BRN/WHT WIRE
CRUISE CONTROL SYSTEM
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH)
DEACTIVATOR SWITCH (ON BRAKE PEDAL SUPPORT)
FEPS KAPWR ISP-R GROUND GROUND GROUND GROUND
FPM ILC HS CAN-
FTPREF SIGRTNC
FUEL PUMP DIODE
FUEL TANK PRESSURE (FTP) SENSOR (UNDER RIGHT SIDE OF VEHICLE)
FUSE 24
FUSE 9
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
OD CANCEL SCCS RTN
POWER STEERING PRESSURE SWITCH (TOP LEFT FRONT OF ENGINE)
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE ENGINE)
PSPSW
RED/WHT WIRE
SHIFT INTERLOCK SYSTEM CRUISE CONTROL SYSTEM
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE SNS OF DASH)
SMR/START
STARTING/CHARGING SYSTEM
STARTING/CHARGING SYSTEM ANTI-LOCK BRAKES SYSTEM
VIO/GRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
VPWR VPWR RLY CTRL SMCS
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
WIPER/WASHER SYSTEM STARTING/CHARGING SYSTEM
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 4.0l (1 of 5) -> FUEL PUMP DIODE
