Mercury Mountaineer III (2005-2010) del acc Wiring diagram
This page shows the only wiring diagram for the component.del acc, which is found in the car Mercury Mountaineer III (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram del acc (1 of 1)
1 2 3 4 5 6 7 8 9 10 GND
ACCESSORY DELAY RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BRN WIRE
CLOSE
DEL ACC
FUSE 1
FUSE 5
HOT AT ALL TIMES
OPEN B+
RED WIRE
ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF)
ROOF OPENING PANEL SWITCH
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TAN WIRE
VIO WIRE
VIO/BRN WIRE
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power top/sunroof circuit, with medium overhead console -> DEL ACC
