Car Wiring Diagrams for Front wiper/washer circuit for Mercury Mountaineer II (2001-2005)

1 PNK/ WIRE BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DK BLU WIRE FRONT WASHER PUMP RELAY FUSE 21 FUSE 4 GRY WIRE HALL SENSOR HOT AT ALL TIMES HOT IN RUN OR ACC INTERVAL SWITCH LT BLU WIRE LT GRN WIRE MICROPROCESSOR ORG/ WIRE PNK WIRE POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE BULKHEAD) REAR WIPER MOTOR REAR WASHER PUMP RELAY ASSEMBLY VIO WIRE WASHER SWITCH WHT WIRE WINDSHIELD WASHER PUMP MOTOR (IN WASHER RESERVOIR) WIPER HIGH/LOW RELAY WIPER RUN/PARK RELAY YEL WIRE
