Car Wiring Diagrams for Passenger power seat circuit for Mercury Mountaineer II (2001-2005)

ADJUSTABLE PEDAL SWITCH (BEHIND LEFT SIDE OF DASH) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE DN UP ENTIRE SEAT FORWARD/REARWARD FUSE 34 HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE NCA WIRE RED WIRE RED/WHT WIRE RIGHT POWER SEAT MOTOR ASSEMBLY RIGHT POWER SEAT SWITCH RWD FWD UP/DOWN FRONT UP/DOWN REAR WHT WIRE YEL WIRE
