Courtesy lamps circuit, except base for Mercury Mountaineer II (2001-2005)
Courtesy lamps circuit, except base (1 of 2)
ACCESSORY DELAY RELAY
BATTERY SAVER RELAY
BLK WIRE
BLK/LT BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
EARLY PRODUCTION
FUSE 17
FUSE 26
GLOVE BOX LAMP)
GRY WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
JOINT CONNECTOR 3
LATE PRODUCTION
LEFT EXTERIOR REAR VIEW MIRROR
LT BLU WIRE
LT GRN WIRE
LT GRN/ORG WIRE
MICROPROCESSOR
ORG/ WIRE
PNK WIRE
PUDDLE LAMP
PUDDLE LAMP RELAY
REAR AUXILIARY JUNCTION BOX (ON RIGHT "D" PILLAR)
RIGHT EXTERIOR REAR VIEW MIRROR
VIO WIRE
VIO/ORG WIRE
YEL WIRE
YEL/LT BLU WIRE
Courtesy lamps circuit, except base (2 of 2)
BLK WIRE
BLK/LT BLU WIRE
EXCEPT LATE PRODUCTION W/ MEDIUM OVERHEAD CONSOLE
FRONT INTERIOR/ MAP LAMPS ASSEMBLY
FRONT INTERIOR/ MAP LAMPS ASSEMBLY INTERIOR LAMP
HOMELINK MODULE VPWR
INTERIOR LAMP
LATE PRODUCTION W/ MEDIUM OVERHEAD CONSOLE
LEFT VANITY MIRROR LAMP
LT BLU WIRE
LT GRN WIRE
LT GRN/ORG WIRE
OFF
OFF MAP LAMPS
ON ON
ORG/ WIRE
RIGHT VANITY MIRROR LAMP
