Manual a/c circuit, without sliding roof for Mercury Mountaineer II (2001-2005)

10 5 1 4 6 11 ILLLUMINATION VPWR VPWR EXTERIOR LIGHTS INPUT GROUND GROUND 12 9 7 REAR WINDOW DEFROST SW A/C DEMAND SIGNAL BLOWER MOTOR TO BLOWER SWITCH A/C CLUTCH CYCLING PRESSURE SWITCH (RIGHT SIDE OF ENGINE COMPARTMENT) A/C CLUTCH RELAY A/C CLUTCH SOLENOID (AT LEFT SIDE OF ENGINE) A/C HIGH PRESSURE SWITCH (LEFT FRONT OF ENGINE COMPT) A/C INDICATOR DIODE BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLEND DR OUTPUT BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BLOWER MOTOR SWITCH BRN WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DK BLU WIRE DK GRN/ORG WIRE DK GRN/VIO WIRE EXCEPT BASE FRONT BLOWER MOTOR (BEHIND CENTER OF DASH) FRONT BLOWER MOTOR RESISTOR ASSEMBLY (BEHIND CENTER OF DASH) FUNCTION SELECTOR SWITCH ASSEMBLY FUSE 10 FUSE 16 FUSE 30 FUSE 36 FUSE 37 FUSE 7 GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HIGH SPEED FAN CONTROL RELAY (BEHIND CENTER OF DASH) HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT CLUSTER J/C 2 LT BLU/ORG WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE MED 1 LOW HIGH MED 2 MEDIUM MICROPRO- CESSOR MODE SWITCH OFF FLOOR/VENT FLOOR MIX VENT MAX DEF ORG/BLK WIRE PNK/WHT WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (AT RIGHT SIDE ENGINE BULKHEAD) RED/BLK WIRE RED/ORG WIRE RED/YEL WIRE TEMPERATURE BLEND DOOR ACTUATOR (BELOW LEFT REAR CARGO AREA WINDOW) VIO WIRE VIO/YEL WIRE VPWR GROUND YEL/BLK WIRE YEL/RED WIRE

1 2 3 4 5 6 GROUND REAR A/C FRONT TO REAR A/C REAR REAR BLOWER TO AUX A/C MODULE AUXILIARY A/C RELAY (BEHIND LEFT SIDE OF REAR SEATS) AUXILIARY BLOWER MOTOR (LEFT SIDE OF CARGO AREA) AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY (IN LEFT REAR CARGO AREA) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLOWER MOTOR HIGH BLOWER MOTOR RESISTOR HIGH BRN WIRE BRN/ORG WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 25 DK GRN/YEL WIRE FUSE 33 GROUND REAR A/C FRONT TO REAR A/C REAR GRY/LT BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT ILLUMINATION INPUT LT BLU/ORG WIRE LT GRN WIRE ORG/BLK WIRE ORG/RED WIRE PNK/WHT WIRE REAR A/C CONTROL MODULE (FRONT) (IN ROOF PANEL) REAR A/C CONTROL MODULE (REAR) (IN ROOF PANEL) REAR MODE DOOR ACTUATOR (LEFT SIDE, BEHIND REAR SEATS) RED/BLK WIRE RED/ORG WIRE TEMPERATURE BLEND DOOR ACTUATOR (BELOW LEFT REAR CARGO AREA WINDOW) WHT WIRE YEL WIRE YEL/BLK WIRE
