Mercury Mountaineer II (2001-2005) left outer parking aid sensor wiring diagram
This page shows the only wiring diagram for the component.left outer parking aid sensor, which is found in the car Mercury Mountaineer II (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left outer parking aid sensor wiring diagram (1 of 1)
BLK WIRE
BLK/PNK WIRE
BRN/PNK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
EXTERIOR LIGHTS, MIRRORS SYSTEMS
FUSE 26
FUSE 27
GROUND
HOT IN RUN OR START
ISO
LEFT INNER PARKING AID SENSOR
LEFT INNER SENSOR INPUT
LEFT OUTER PARKING AID SENSOR
LEFT OUTER SENSOR INPUT
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
ON/OFF SWITCH
ORG/ WIRE
PARKING AID DISABLE SWITCH
PARKING AID MODULE (AT RIGHT "D" PILLAR)
PARKING AID SPEAKER (AT RIGHT ``D" PILLAR)
PNK STATUS LED WIRE
PNK WIRE
POWER
REAR SOUNDER -
RED WIRE
RED/BLK WIRE
REVERSE INPUT
RIGHT INNER PARKING AID SENSOR
RIGHT INNER SENSOR INPUT
RIGHT OUTER PARKING AID SENSOR
RIGHT OUTER SENSOR INPUT
SENSOR GROUND
SENSOR POWER
WHT/LT BLU WIRE
WHT/LT GRN WIRE
YEL WIRE
Go to component -> Navigation circuit -> LEFT OUTER PARKING AID SENSOR
