Mercury Mountaineer II (2001-2005) (in pia wiring harness, near breakout to Wiring diagram
This page shows the only wiring diagram for the component.(in pia wiring harness, near breakout to, which is found in the car Mercury Mountaineer II (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in pia wiring harness, near breakout to (1 of 1)
BLK WIRE
BLK/LT BLU WIRE
EXCEPT LATE PRODUCTION W/ MEDIUM OVERHEAD CONSOLE
FRONT INTERIOR/ MAP LAMPS ASSEMBLY
FRONT INTERIOR/ MAP LAMPS ASSEMBLY INTERIOR LAMP
HOMELINK MODULE VPWR
INTERIOR LAMP
LATE PRODUCTION W/ MEDIUM OVERHEAD CONSOLE
LEFT VANITY MIRROR LAMP
LT BLU WIRE
LT GRN WIRE
LT GRN/ORG WIRE
OFF
OFF MAP LAMPS
ON ON
ORG/ WIRE
RIGHT VANITY MIRROR LAMP
Go to component -> Courtesy lamps circuit, except base (2 of 2) -> (IN PIA WIRING HARNESS, NEAR BREAKOUT TO
