Mercury Mountaineer II (2001-2005) (in interior illumination harness, near breakout Wiring diagram
This page shows the only wiring diagram for the component.(in interior illumination harness, near breakout, which is found in the car Mercury Mountaineer II (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in interior illumination harness, near breakout (1 of 1)
ACCESSORY DELAY RELAY
BATTERY SAVER RELAY
BLK WIRE
BLK/LT BLU WIRE
CARGO LAMP ASSEMBLY OFF
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
FRONT INTERIOR/ MAP LAMPS ASSEMBLY
FUSE 17
GLOVE BOX LAMP)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTERIOR LAMP
JOINT CONNECTOR 4
LT BLU WIRE
LT GRN WIRE
MAP LAMPS
MICROPROCESSOR
ON LIFTGATE OPEN
ORG/ WIRE
REAR AUXILIARY JUNCTION BOX (ON RIGHT "D" PILLAR)
REAR INTERIOR/ MAP LAMPS ASSEMBLY
VIO WIRE
VIO/ORG WIRE
W/O OVERHEAD CONSOLE
YEL/LT BLU WIRE
Go to component -> Courtesy lamps circuit, base -> (IN INTERIOR ILLUMINATION HARNESS, NEAR BREAKOUT
